| Features | |
 | |
|
| Series | AEC-Q200 |
High Ripple Current |
High Temperature | Low ESR | Long Life |
Miniaturized Size |
Photo Flash / Pulse |
Standard Size |
Ultra Long Life | Vibration Proof |
Temperature Range (°C) |
Voltage Range (V) |
Capacitance Range (µF) |
Endurance (hours) | Useful Life (hours) | Series Datasheets | ||||
| SF |
 |
● | -20 | 55 | 330 | 350 | 150 | 1500 | 5000 times |
 |
||||||||||
| LP |
 |
● | -40 | 85 | 6.3 | 350 | 100 | 100mF | 2000 | 3000 to 5000 |
|
|||||||||
| -25 | 385 | 600 | 22 | 2700 | ||||||||||||||||
| UB |
|
● | -40 | 85 | 200 | 450 | 68 | 3300 | 2000 | 5000 |
|
|||||||||
| -25 | 500 | 100 | 1500 | |||||||||||||||||
| UC |
|
● | -40 | 85 | 200 | 450 | 68 | 2700 | 3000 | 7000 |
|
|||||||||
| -25 | 500 | 630 | 56 | 1500 | ||||||||||||||||
| UD |
|
● | ● | -40 | 85 | 200 | 450 | 68 | 2700 | 5000 | 10000 |
|
||||||||
| -25 | 500 | 600 | 47 | 680 | ||||||||||||||||
| HP |
|
● | -40 | 105 | 6.3 | 350 | 68 | 100mF | 2000 | 3000 to 5000 |
|
|||||||||
| -25 | 400 | 550 | 47 | 1200 | ||||||||||||||||
| UJ |
|
● | ● | -40 | 105 | 200 | 450 | 82 | 3300 | 2000 | 5000 |
|
||||||||
| -25 | 500 | 550 | 47 | 1000 | ||||||||||||||||
| UK |
|
● | ● | -40 | 105 | 200 | 450 | 68 | 2200 | 3000 | 8000 |
|
||||||||
| -25 | 500 | 550 | 47 | 680 | ||||||||||||||||
| UE |
 |
● | ● | -40 | 105 | 160 | 450 | 120 | 4700 | 3000 | 8000 |
|
||||||||
| -25 | 475 | 500 | 68 | 820 | ||||||||||||||||
| UA |
|
● | ● | ● | -40 | 105 | 160 | 450 | 56 | 3300 | 3000 | 8000 |
|
|||||||
| UL |
|
● | ● | ● | -40 | 105 | 200 | 450 | 82 | 2700 | 5000 | 10000 |
|
|||||||
| -25 | 500 | 550 | 47 | 680 | ||||||||||||||||
| UG |
|
● | ● | ● | -40 | 105 | 400 | 450 | 120 | 1200 | 5000 | 10000 |
|
|||||||
| -25 | 475 | 500 | 68 | 820 | ||||||||||||||||
| UF |
|
● | ● | ● | ● | -40 | 105 | 200 | 450 | 100 | 2700 | 5000 | 10000 |
|
||||||
| -25 | 475 | 500 | 56 | 560 | ||||||||||||||||
| UM |
|
● | ● | -40 | 105 | 160 | 450 | 47 | 2200 | 7000 | 10000 |
|
||||||||
| UH |
|
● | ● | -40 | 105 | 200 | 450 | 39 | 1500 | 10000 | 12000 |
|
||||||||
| HC |
|
● | ● | ● | ● | ● | ● | -55 | 125 | 25 | 63 | 600 | 3300 | 3000 | 4000 |
|
||||
| HH |
|
● | ● | ● | -40 | 125 | 400 | 450 | 47 | 560 | 3000 | 4000 |
|
|||||||
| Legend |
|
Economy Series | Not for 24h continuous applications |
|
|
High Reliability Series | For 7days / 24h continuous applications | |
|
|
New Product Series | For 7days / 24h continuous applications |
| Related technical documentation: |
General Precautions & Guidelines | Packaging Information | ||
|
| ||
|
| ||
| Includes following information: | Includes following information: | ||
| Precautions and handling guidelines for all product technologies |
| Product code configuration and technical options |
| Soldering profiles and restrictions |
| Available packaging styles and packaging units |
Vibration Specification | 3D - Models |
| |
| |
| Includes following information: | Includes following information: |
Vibration Test Profiles | Library of 3D STP-files |
Reliability Tests |
|
|
|
|
|
| Includes following information: | |
Test specification and criteria |
|
