Precautions & Packaging Information
Aluminum Electrolytic Capacitors – Radial
2020-06-29



Features









SeriesAEC-Q200Bi-PolarHigh TemperatureLow ESRLow HeightLow LeakageOvervoltage VentPhoto FlashSlim TypeStandardUltra Long LifeUltra Low ESRUltra MiniaturizedTemperature Range(°C) Voltage Range(V) Capacitance Range(µF) Endurance(hours) Series Datasheet
RF                         -20 55 330 350 100  450 5000 times
SS                       -40 85 4 50 0.1 330 1000
SM                       -40 85 4 63 0.1 470 1000
SR                         -40 85 6.3 50 0.1 220 1000
SW                         -40 85 4 50 0.1 470 1000
SH                       -40 85 4 63 0.1 470 2000
RW                         -40 85 6.3 160 0.1 33000 2000
NR                         -40 85 6.3 100 0.15 1000 2000
GS                         -40 85 6.3 100 0.1 33000 2000
-25 160 450 0.47 560
NP                         -40 85 6.3 100 0.47 3300 2000
-25 160 250 0.47 47
ST                       -40 105 4 50 0.1 220 1000
SK                       -40 105 4 63 0.1 470 1000
SZ                       -55 105 6.3 35 6.8 330 1000
KZ                         -40 105 6.3 50 0.47 6800 1000 to 2000
KS                         -25 105 200 400 4.7 400 2000
KY                         -25 105 250 450 12 150 2000
KM                         -40 105 6.3 100 0.1 22000 2000
-25 160 500 0.47 560
NK                         -40 105 6.3 100 0.47 3300 2000
-25 160 250 0.47 47
SJ                       -40 105 6.3 63 0.1 220 2000
LL                         -40 105 6.3 63 0.1 2200 2000
LZ                         -40 105 6.3 25 220 3300 2000
SY                       -55 105 6.3 50 1 330 2000
KF                         -40 105 6.3 100 0.47 15000 2000 to 5000
-25 160 450 0.47 330
GF                         -40 105 6.3 100 4.7 6800 2000 to 5000
KC                       -25 105 400 450 82 220 3000
SG                     -40 105 6.3 50 0.1 470 4000
FH                         -40 105 6.3 100 6.8 18000 4000 to 10000
LY                         -25 105 250 450 12 150 5000
KL                       -40 105 160 400 3.3 330 5000
-25 450 500 2.2 180
GH                       -55 105 6.3 100 0.47 12000 5000 to 10000
KH                         -40 105 10 400 6.8 3300 5000 to 10000
-25 450   6.8 100
FK                       -40 105 160 450 1 330 6000 to 8000
-25 500   4.7 120
ZH                         -40 105 6.3 100 8.2 8200 6000 to 10000
FL                       -40 105 160 450 1 680 8000 to 12000
-25 105 500   10 68
HY                         -25 105 250 450 12 120 10000
GT                       -40 105 10 100 1 330 10000
LE                         -40 105 160 450 1 68 12000 to 20000
TH                       -40 125 10 400 0.47 8200 1000 to 3000
-25 450   1 47
TE                       -40 130 10 400 2.2 4700 1000 to 3000



 Related technical documentation:

General Precautions & Guidelines

Packaging Information

Includes following information: Includes following information:

Precautions and handling guidelines for all product technologies

Product code configuration and technical options

  Soldering profiles and restrictions

Available packaging styles and packaging units



3D - Models

Reliability Tests







Includes following information:Includes following information:

Library of 3D STP-files

Test specification and criteria
